Overhead UV LED NDT Lamp LUYOR-3124

High-intensity ASTM compliant broad-beam flood lamp for overhead nondestructive

Send Inquiry

Product Details

High-intensity ASTM compliant broad-beam flood lamp for overhead nondestructive testing inspections.

LUYOR-3124 Overhead UV LED NDT Lamp is excellent for stationary use in fluorescent detection and fluorescent magnetic particle inspection. With a flexible arm, NDT professionals can easily adjust the angle to meet specific inspection requirements. Equipped with 24 high-performance UV LEDs, LUYOR-3124 provides wide-area, intense, and uniform ultraviolet output.

Product Advantages

24 UV-A LEDs provide a wide area of uniform coverage and stable ultraviolet rays

ASTM compliant, ideal for overhead non-destructive testing

Instant-on operation ensures that each of the UV-A LEDs reaches full intensity quickly

Flexible arm for mounting at specific angles

Easily mountable for overhead inspection or in-line applications

Built-in black UV filter reduces visible wavelength

Long-lasting UV-A lenses eliminate clouding/solarization

Long-life LEDs ensure years of use with minimum maintenance

Durable housing designed for years of use in heavy-duty work environments

More efficient and longer lifetime compared to high-pressure mercury lamps

The fanless design allows cool running and minimum background noise

Technical Data

Light source: 24 UV LEDs

Wavelength: 360-370nm, peak wavelength 365nm

White light measurement: 14.23 lux

LED lifetime: > 50,000 hours

Power supply: 100-240V, 50/60Hz

Cooling: fanless cooling design

Filter: black UV filter

Applications

Non-destructive testing

Fluorescent penetrant inspection

Fluorescent magnetic particle inspection

Fluorescent Inspection Solutions for High-Speed Train Steel Wheels and Brake Discs:

On the fluorescent inspection line for high-speed train steel wheels, install one LUYOR-3121 fluorescent inspection lamp on each side (left and right). Additionally, install one LUYOR-3106 inspection lamp on the wheel tread surface. The LUYOR-3121 fluorescent inspection lamp offers an effective irradiation area of up to 60 × 25 cm. Compared with traditional 400 W inspection lamps, the LUYOR-3121 is compact in size and, when installed on the steel wheel inspection line, does not interfere with workers' visual inspection. Its irradiation area fully covers the wheel radius, ensuring that the steel wheel is inspected without any blind spots.

Fluorescent Inspection Solution for High-Speed Train Axles:

The LUYOR-3121 fluorescent inspection lamp is compact in size, making it easy to combine multiple units for fluorescent inspection. For axle inspection, users can connect two LUYOR-3121 lamps in series. When used together, the two lamps provide a combined irradiation area of up to 120 × 25 cm, fully meeting the requirements for axle inspection.

At LUYOR, we provide customers with complete fluorescent inspection solutions and customize special fluorescent inspection light sources according to customer requirements. For more details, please contact us.

Q: Why Choose LUYOR?

A: With over 20 years of experience in UV and specialized lighting solutions, we are confident that we can provide efficient and economical products for your specific needs.

Q: How do I know which product is right for me?

A: At LUYOR, our experienced team will help you find the most suitable solution for your specific application. Leave a message below or email us at info@luyorgroup.com.
